Local-Mode SED from a LAMMPS Run

This tutorial shows the full local-mode SED workflow starting from a LAMMPS MD run. The target signal is a Ti-centered local polar distortion d(Ti) and its time derivative, not an all-atom velocity field. The workflow is:

  1. write the local Ti displacement and displacement velocity from LAMMPS

  2. convert the LAMMPS text dump to npy arrays on a fixed grid

  3. calculate and plot the local-mode SED with ferrodispcalc.sed

The example uses LAMMPS metal units:

  • time in ps

  • displacement in Angstrom

  • velocity in Angstrom/ps

With dt_ps in ps, numpy.fft.fftfreq returns frequency in 1/ps, which is numerically THz.

LAMMPS Setup

Only the SED-specific LAMMPS setup is shown here. The force field, thermostat, cell setup, and equilibration details are not part of the SED interface.

atom_style      atomic
units           metal
atom_modify     map array
comm_modify     vel yes

plugin load     /path/to/ferrodispcalc/src/lammps/dispplugin.so
plugin list

timestep        0.001
variable        dt_dump equal 10

compute         1 all disp/atom nnfile ./structure/nl-bo.dat vel yes
group           Ti type 3
dump            dipole Ti custom ${dt_dump} dipole.dat \
                id type c_1[1] c_1[2] c_1[3] c_1[4] c_1[5] c_1[6]
dump_modify     dipole sort id

The plugin command compute ... disp/atom reads the neighbor-list file nl-bo.dat and computes six values for each selected Ti atom:

  • c_1[1:3]: local Ti displacement d(Ti)

  • c_1[4:6]: local Ti displacement velocity

comm_modify vel yes is required when velocity output is requested with vel yes. Dump sorting by atom id makes the downstream grid mapping stable. If the production dump is written to dipole.dat with stride dt_dump = 10 and timestep 0.001 ps, the stored-frame spacing is dt_ps = 0.01 ps.

Convert dipole.dat to dipole.npy

The following script converts the LAMMPS text dump to a fixed-grid numpy array. It assumes the current directory contains:

  • dipole.dat from the LAMMPS dump dipole command

  • structure/model.xyz for the structure used to define the grid

Save this as load_dipole_data.py and adjust nframe, natom, and target_size for your system.

import numpy as np
from tqdm import tqdm
from ase.io import read

from ferrodispcalc.vis import grid_data


def load_c1_to_npy(
    dump_file,
    out_file="c1.npy",
    nframe=100001,
    natom=3600,
    dtype=np.float64,
):
    c1_out = np.lib.format.open_memmap(
        out_file,
        mode="w+",
        dtype=dtype,
        shape=(nframe, natom, 6),
    )
    timesteps = np.empty(nframe, dtype=np.int64)
    cidx = None
    ncol = None

    with open(dump_file, "rb") as f:
        for iframe in tqdm(range(nframe), desc="Reading frames"):
            f.readline()                         # ITEM: TIMESTEP
            timesteps[iframe] = int(f.readline())

            f.readline()                         # ITEM: NUMBER OF ATOMS
            f.readline()                         # natom

            f.readline()                         # ITEM: BOX BOUNDS ...
            f.readline()
            f.readline()
            f.readline()

            atoms_header = f.readline().decode("ascii").split()
            columns = atoms_header[2:]

            if cidx is None:
                wanted_cols = [f"c_1[{i}]" for i in range(1, 7)]
                cidx = [columns.index(name) for name in wanted_cols]
                ncol = len(columns)

            block = b"".join(f.readline() for _ in range(natom))
            arr = np.fromstring(block, sep=" ", dtype=dtype).reshape(
                natom,
                ncol,
            )
            c1_out[iframe] = arr[:, cidx]

    np.save("timesteps.npy", timesteps)
    del c1_out
    return out_file


# Step 1: text dump -> c1.npy with shape (nframe, n_Ti, 6)
load_c1_to_npy(
    dump_file="dipole.dat",
    out_file="c1.npy",
    nframe=100001,
    natom=3600,
    dtype=np.float64,
)

# Step 2: atom-wise Ti data -> fixed grid
c1 = np.load("c1.npy", mmap_mode="r")
atoms = read("structure/model.xyz")
dipole = grid_data(
    atoms,
    c1,
    ["Ti"],
    target_size=[6, 6, 100],
)
np.save("dipole.npy", dipole)

The intermediate c1.npy has shape (nframe, n_Ti, 6). The final dipole.npy has shape (nframe, nx, ny, nz, 6):

  • dipole[..., 0:3]: d(Ti)

  • dipole[..., 3:6]: velocity of d(Ti)

Run the conversion in the directory containing dipole.dat:

python load_dipole_data.py

If c1.npy already exists, you can comment out the load_c1_to_npy call and regenerate only dipole.npy from the mapped structure.

Calculate SED

All SED APIs are imported from ferrodispcalc.sed. The calculation requires explicit q-points. Use generate_commensurate_qpath to create q-points that are allowed by the primitive-cell grid.

from pathlib import Path

import numpy as np

from ferrodispcalc.sed import (
    calculate_sed,
    generate_commensurate_qpath,
    plot_sed,
    save_sed,
)


output_dir = Path("sed-output")
output_dir.mkdir(parents=True, exist_ok=True)

dipole = np.load("dipole.npy", mmap_mode="r")

dt_ps = 0.001 * 10
frame_start = 1
max_frames = 100000
primitive_shape = (1, 1, 1)
num_splits = 5
n_jobs = 4

q_path = np.array(
    [
        [0.0, 0.0, 0.0],
        [0.0, 0.0, 0.5],
    ],
    dtype=float,
)

grid_shape = tuple(int(v) for v in dipole.shape[1:4])
cell_shape = tuple(g // p for g, p in zip(grid_shape, primitive_shape))
qpoints, q_distances = generate_commensurate_qpath(q_path, cell_shape)

stop = frame_start + max_frames

dti = dipole[frame_start:stop, :, :, :, 0:3]
dti_result = calculate_sed(
    field=dti,
    dt_ps=dt_ps,
    qpoints=qpoints,
    primitive_shape=primitive_shape,
    num_splits=num_splits,
    remove_mean=True,
    n_jobs=n_jobs,
)
save_sed(dti_result, output_dir / "dTi_displacement.npz")

velocity = dipole[frame_start:stop, :, :, :, 3:6]
velocity_result = calculate_sed(
    field=velocity,
    dt_ps=dt_ps,
    qpoints=qpoints,
    primitive_shape=primitive_shape,
    num_splits=num_splits,
    remove_mean=False,
    n_jobs=n_jobs,
)
save_sed(velocity_result, output_dir / "dTi_velocity.npz")
np.save(output_dir / "q_distances.npy", q_distances)

plot_sed(
    velocity_result,
    q_distances=q_distances,
    component="total",
    q_labels=(r"$\Gamma$", "Z"),
    savepath=output_dir / "dTi_velocity-total-SED.png",
)

For displacement-like fields, set remove_mean=True to remove the static local distortion and the DC component before the time Fourier transform. For velocity-like fields, use remove_mean=False.

Reference Output

../_images/dTi_velocity-total-SED.png

Total SED intensity for the Ti displacement velocity field along Gamma -> Z.

q-Point and Primitive-Cell Convention

calculate_sed does not generate q-points internally. The q-points are reduced coordinates with shape (nq, 3) and use the phase convention exp(+i * 2*pi * dot(q, cell_index)).

For an input grid (nx, ny, nz) and primitive_shape=(px, py, pz), the number of primitive cells is:

cell_shape = (nx // px, ny // py, nz // pz)
qpoints, q_distances = generate_commensurate_qpath(q_path, cell_shape)

Allowed reduced q-points satisfy q * cell_shape being integer-valued. Changing primitive_shape changes which grid points are treated as basis local modes inside one primitive cell. For example, primitive_shape=(1, 1, 5) treats five local modes along z as basis modes and reduces the number of primitive cells along z by a factor of five.

SED Array Convention

The returned result.sed array has shape (nfreq, nq, 4). The last axis is ordered as:

  • 0: x component

  • 1: y component

  • 2: z component

  • 3: total, equal to x + y + z

The normalization is 1 / (Nt * Ncell) before averaging over time blocks, where Nt is the number of frames in one block and Ncell is the number of primitive cells. No mass weighting is applied. The absolute intensity is therefore an internal convention for the chosen local variable; peak positions, frequency axis, and q-point dispersion are the robust comparison targets.

Loading and Replotting

Use save_sed and load_sed for the compressed npz format:

import numpy as np

from ferrodispcalc.sed import load_sed, plot_sed

loaded = load_sed("sed-output/dTi_velocity.npz")
q_distances = np.load("sed-output/q_distances.npy")

plot_sed(
    loaded,
    q_distances=q_distances,
    component="z",
    q_labels=(r"$\Gamma$", "Z"),
    savepath="sed-output/dTi_velocity-z-SED.png",
)

See calculate_sed(), generate_commensurate_qpath(), load_sed(), save_sed(), and plot_sed() for API details.
